High Concentration: Rice cake batter (non-fermented), glutinous rice paste (non-fermented), honey, chocolate, oyster sauce, pear syrup, donkey-hide gelatin paste, strawberry jam, durian jam, custard sauce, Mexican sauce, sesame paste, ketchup, minced meat, pet biscuit dough, etc.
Medium Concentration: Cream, mousse batter, semi-cooked cheese, cake batter, jar cake, sesame brittle dough, pancake batter, yogurt, coconut paste, sweet sauce, roast duck sauce, honey sauce, curry sauce, edible gelatin, etc.
Low Concentration: Egg tart liquid, rock candy cake, rice paste (non-fermented), egg liquid, pudding liquid, edible oil, red oil, abalone soup, noodle soup, Buddha jumps over the wall soup, sea buckthorn paste, milk skin paste, ice cream liquid, etc.
- Equipment model number 2-X
- Outline dimension:405*380*585m
- Rate of flow:10L/min
- Rated voltage:100-240V
- Rated power: ≤260W
- Gross weight: 17 kg
- Warranty:2 years
SKU | Image | Model | Brix | Rated Voltage | Rated Power | Weight | Packing | Pump Type | Flow Rate | Viscosity Capacity | Bottle Height | More Info |
---|---|---|---|---|---|---|---|---|---|---|---|---|
3-X-FM | ![]() |
3-X (Conveyor) | For honey < 44°Bx | 110V-240V | ≤120w | 10kg | 310*168*245mm | Gear | 900-1000L/h | 1000CP-18000CP | / | View Details |
4-XP-FM | ![]() |
4-XP | For honey < 42.5°Bx and T > 20°C | DC12V AC100-240V | ≤120w | 9KG | 400*400*250mm | Gear | 4.5L/min | 1000CP-18000CP | 20g-5000g | View Details |
5-X-FM | ![]() |
5-X | For honey < 42.5°Bx and T > 20°C | DC24V AC100-240V | ≤120w | 10KG | 400*400*250mm | Gear | 6L/min | 1000CP-18000CP | 30g-6000g | View Details |
5-XP-FM | ![]() |
5-XP | For honey < 43.5°Bx and T > 10°C | DC24V AC100-240V | ≤250w | 13KG | 400*400*320mm | Gear | 10L/min | 1000CP-18000CP | 30g-10000g | View Details |
6-XP-FM | ![]() |
6-XP | For honey < 43.5°Bx and T > 10°C | DC24V AC100-240V | ≤250w | 13KG | 400*400*320mm | Gear | 10L/min | 1000CP-18000CP | 30g-10000g | View Details |
7-X-FM | ![]() |
7-X | For honey < 43.5°Bx and T > 10°C | DC24V AC100-240V | ≤250w | 35KG | 605*495*510mm | Gear | 20L/min | 1000CP-18000CP | 50g-10000g | View Details |
8-X-2-FM | ![]() |
8-X-2 | For honey < 43.5°Bx and T > 10°C | 110V-240V | ≤260w | 25KG | 580*420*400mm | Gear | 11L/min | 1000cp-18000cp | 10g-10000g | View Details |
8-X-1-FM | ![]() |
8-X-1 | For honey < 43.5°Bx and T > 10°C | 110V-240V | ≤260w | 25KG | 580*420*400mm | Gear | 11L/min | 1000cp-18000cp | 10g-10000g | View Details |
9-X-2-FM | ![]() |
9-X-2 | For honey < 42.5°Bx and T > 10°C | 110V-240V | ≤260w | 20KG | 500*350*350mm | Gear, Impeller, Peristaltic | 15L/min | 50cp-10000cp | ≥1g | View Details |
9-X-1-FM | ![]() |
9-X-1 | For honey < 42.5°Bx and T > 10°C | 110V-240V | ≤260w | 20KG | 500*350*350mm | Gear, Impeller, Peristaltic | 15L/min | 50cp-10000cp | ≥1g | View Details |
2-X-FM | ![]() |
2-X | For honey < 43.5°Bx and T > 20°C | 110V-240V | ≤260w | 16KG | 405*380*585mm | Gear | 11L/min | 1000cp-18000cp | ≥10g adjustable | View Details |
13-Y-FM | ![]() |
13-Y | 316L pump, can be used for corrosive liquids | 110V-240V | ≤120w | 8KG | 320*260*555mm | Magnetic Gear | 6L/min | 1-100CP | 10g-10000g | View Details |
5-Y-FM | ![]() |
5-Y | Suitable for liquids containing particles ≤ 6mm | 110V-240V | ≤120w | 9KG | 340*260*555mm | Flexible Impeller Pump | 15L/min | / | 100g-10000g | View Details |
8-X-3-FM | ![]() |
8-X-3 | For honey < 43.5°Bx and T > 10°C | 110V-240V | ≤400w | 65KG | 885*670*635mm | Gear | 10L/min | 1000-18000CP | 5g-2000g | View Details |
9-X-4-FM | ![]() |
9-X-4 | For honey < 42.5°Bx and T > 10°C | 110V-240V | ≤400w | 62KG | 850*600*635mm | Gear | 10L/min | 1000-18000CP | 1g-500g | View Details |
L-1-FM | ![]() |
L-1 | 316L (material) | / | / | / | / | / | / | / | / | View Details |
L-2-FM | ![]() |
L-2 | 316L (material) | / | / | / | / | / | / | / | / | View Details |
L-3-FM | ![]() |
L-3 | 316L (material) | / | / | / | / | / | / | / | / | View Details |
L-4-FM | ![]() |
L-4 | 316L (material) | / | / | / | / | / | / | / | / | View Details |
L-5-FM | ![]() |
L-5 | 316L (material) | / | / | / | / | / | / | / | / | View Details |
L-6-FM | ![]() |
L-6 | 316L (material) | / | / | / | / | / | / | / | / | View Details |
L-7-FM | ![]() |
L-7 | 316L (material) | / | / | / | / | / | / | / | / | View Details |
L-8-FM | ![]() |
L-8 | / | / | / | / | / | / | / | / | / | View Details |
L-9-FM | ![]() |
L-9 | / | / | / | / | / | / | / | / | / | View Details |
L-10-FM | ![]() |
L-10 | / | / | / | / | / | / | / | / | / | View Details |
L-11-FM | ![]() |
L-11 | / | / | / | / | / | / | / | / | / | View Details |
Smart Liquid Filling Machine
Automatically adjusts filling parameters, reducing human error and increasing efficiency. Delivers consistent ad precise filling for enhanced product quality. Enhance your production process with the automated filling system, designed to minimize errors and boost productivity. Experience reliable and accurate filling for top-quality products.
